75TAH10TDB Nachi Thrust Angular Contact Bearing 75x115x36 ABEC 7

75TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

• 75TAH10TDB Nachi Ball Bearing
• Nachi Angular Spindle Ball Bearing
• Cage: Phenolic resin
• Dimensions: 75mm x 115mm x 36mm/Metric
• ID (inner diameter)/Bore: 75mm
• OD (outer diameter): 115mm
• Width: 36mm
• Size: 75 x 115 x 36 mm
• Quantity: 1 Bearing
• Dynamic load rating Cr: 35,500 N
• Static load rating Cor: 83,500 N
• Limiting Speed:
  • Grease Lubrication: 7,900 RPM
  • Oil Lubrication: 10,000 RPM
• Made in Japan
